Push-In Wire Connectors, 25, 50, or 100 Pack

Spec Sheet Download

Push-In Wire Connectors, 25, 50, or 100 Pack

Name: Push-In Wire Connectors, 25, 50, or 100 Pack
Brand: Morris GWG
SKU: 23015
Price: 45.00 USD
Availability: InStock

ITEM: 23015

Brand: Morris GWG

Leave a Review

Features include:

Easy Push-In Wire Connectors are simple to install - instead of Twisting or Taping, simply Push Wires Into Contact Port to save you time and money
Accepts Either Stranded or Solid Wire
Low Wire Insertion Force allows fast, easy connections
No-Twist Connection reduces repetitive motion fatigue
Easy Push In Wire Connectors are Re-Useable, making changes easy and reducing waste of connectors
Clear Housing for Visible Connection Confirmation
Check Port for Continuity Testing
Electrolytic Tin-Plated Internal Copper Bus for high conductivity
Housing Material: Thermoplastic, UL 94V-2 flame retardant
Current: 24A (VDE)
Voltage: UL-600V, VDE-450V
Working Temperature: 230;F (110C)
Wire Range: 12-22 AWG Solid conductor
Color Coded according to # of poles
cULus Listed
Copper Wire Only
(Bag 25 Pack) Order Qty of 25 = 1 Bag of 25

[{"id":40082036916361,"title":"5 Pole Gray Boxed 100 Pack","option1":"5 Pole Gray Boxed 100 Pack","option2":null,"option3":null,"sku":"23015","requires_shipping":true,"taxable":true,"featured_image":{"id":29168610115721,"product_id":2840561680484,"position":6,"created_at":"2022-03-10T14:41:37-06:00","updated_at":"2022-03-10T14:41:37-06:00","alt":null,"width":220,"height":220,"src":"\/\/www.warehouse-lighting.com\/cdn\/shop\/products\/23225_n.jpg?v=1646944897","variant_ids":[40082036916361,40082038685833]},"available":true,"name":"Push-In Wire Connectors, 25, 50, or 100 Pack - 5 Pole Gray Boxed 100 Pack","public_title":"5 Pole Gray Boxed 100 Pack","options":["5 Pole Gray Boxed 100 Pack"],"price":4500,"weight":454,"compare_at_price":5400,"inventory_management":null,"barcode":null,"featured_media":{"alt":null,"id":21461761851529,"position":6,"preview_image":{"aspect_ratio":1.0,"height":220,"width":220,"src":"\/\/www.warehouse-lighting.com\/cdn\/shop\/products\/23225_n.jpg?v=1646944897"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":27071944491108,"title":"8 Pole Black Hanging Bag 25 Pack","option1":"8 Pole Black Hanging Bag 25 Pack","option2":null,"option3":null,"sku":"23228","requires_shipping":true,"taxable":true,"featured_image":{"id":10428149334116,"product_id":2840561680484,"position":5,"created_at":"2019-05-08T17:02:17-05:00","updated_at":"2019-10-21T22:36:13-05:00","alt":null,"width":500,"height":500,"src":"\/\/www.warehouse-lighting.com\/cdn\/shop\/products\/23228_l_5f73a538-4370-4533-b80a-7ccdb5588639.jpg?v=1571715373","variant_ids":[27071944491108]},"available":true,"name":"Push-In Wire Connectors, 25, 50, or 100 Pack - 8 Pole Black Hanging Bag 25 Pack","public_title":"8 Pole Black Hanging Bag 25 Pack","options":["8 Pole Black Hanging Bag 25 Pack"],"price":2289,"weight":454,"compare_at_price":2747,"inventory_management":null,"barcode":"601986232289","featured_media":{"alt":null,"id":3306410180745,"position":5,"preview_image":{"aspect_ratio":1.0,"height":500,"width":500,"src":"\/\/www.warehouse-lighting.com\/cdn\/shop\/products\/23228_l_5f73a538-4370-4533-b80a-7ccdb5588639.jpg?v=1571715373"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":40082038685833,"title":"8 Pole Black Boxed 50 Pack","option1":"8 Pole Black Boxed 50 Pack","option2":null,"option3":null,"sku":"23018","requires_shipping":true,"taxable":true,"featured_image":{"id":29168610115721,"product_id":2840561680484,"position":6,"created_at":"2022-03-10T14:41:37-06:00","updated_at":"2022-03-10T14:41:37-06:00","alt":null,"width":220,"height":220,"src":"\/\/www.warehouse-lighting.com\/cdn\/shop\/products\/23225_n.jpg?v=1646944897","variant_ids":[40082036916361,40082038685833]},"available":true,"name":"Push-In Wire Connectors, 25, 50, or 100 Pack - 8 Pole Black Boxed 50 Pack","public_title":"8 Pole Black Boxed 50 Pack","options":["8 Pole Black Boxed 50 Pack"],"price":3963,"weight":454,"compare_at_price":4755,"inventory_management":null,"barcode":null,"featured_media":{"alt":null,"id":21461761851529,"position":6,"preview_image":{"aspect_ratio":1.0,"height":220,"width":220,"src":"\/\/www.warehouse-lighting.com\/cdn\/shop\/products\/23225_n.jpg?v=1646944897"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

Usually Ships in

7-10 Business Days
